FIX-PA Insulation Fixing 10.0 x 220mm
FIX-PA Insulation Fixing 10.0 x 220mm FIX-PA Insulation Fixing 10.0 x 220mm FIX-PA Insulation Fixing 10.0 x 220mm

FIX-PA Insulation Fixing 10.0 x 220mm

£21.29per Box £25.55 inc VAT
TIMCO Logo
Size

Size

Length

Qty:
- +
110 In Stock
Product Code: PA220
Brand: TIMCO

Ziel-Plast FIX-PA Insulation Fixing 220mm — Heavy-Duty ETICS Anchor

For deep systems and taller runs, the Ziel-Plast FIX-PA Insulation Fixing 220mm by TIMCO provides stable anchorage with a low-profile head. The fast hammer-in method keeps productivity high while supporting plane uniformity.

Product Overview

  • Useful on deeper facades and perimeter zones where densities increase.
  • Defined head stop aids consistent pacing on repetitive fixing layouts.
  • 60mm plate head assists smooth transitions around openings and corners.
  • Manages adhesive/board variance to keep the facade plane true.
  • Compatible with ETICS grids and verification routines as specified.

Product Features

  • PA pin and insulating sleeve provide dependable hold with reduced thermal bridging.
  • Expansion design supports repeatable engagement in concrete, brick, and block.
  • Short/long anchoring zones offer setup flexibility under site conditions.
  • Broad head distributes pressure to help protect board faces.
  • Pairs with TDW110 washers where the specification calls for wider bearing.
  • Positive seating aids flush alignment across large fields.

Specifications

  • Length: 220mm
  • Diameter: 10.0mm
  • Material: Insulating Sleeve (Polymer), Polyamide (PA) Pin
  • Application: Facade Insulation Systems, External Thermal Insulation Composite Systems (ETICS)
  • CE Standard: CE Marked
  • Substrates: Concrete, Brick, Block
  • Brand: Ziel-Plast
  • MOQ: 1
  • Pack Type: Box
  • Pack Quantity: 100
  • Head Diameter: 60mm
  • Colour: White
  • Drill Hole Diameter: 10mm
  • Anchoring Zones: Short/Long
  • Product Code: PA220
  • Brand: TIMCO

Why Choose Ziel-Plast FIX-PA?

PA220 delivers the extra travel needed for deeper layers while helping keep surfaces even around reveals and perimeter zones.



EAN Code: 5908275918349

  • Length mm: 220
  • Material: Polypropylene (PP) Sleeve, Galvanised Steel Pin
  • Application: Facade Insulation Systems, External Thermal Insulation Composite Systems (ETICS)
  • CE Standard: CE Marked
  • Substrates: Concrete Brick Block
  • Brand: Ziel-Plast
  • MOQ: 1
  • Pack Type: Box
  • Pack Quantity: 100
  • Head Dia. mm: 60
  • Colour: White
  • Drill Hole Dia. mm: 10
  • Thread Dia. mm: 10
